1. Flat, Open Deck
No walls or roof – just a flat horizontal platform.

Ideal for irregular, oversized, or heavy cargo.

2. Multiple Length Options
Common lengths: 20ft, 40ft, 45ft, 48ft, 53ft.

Length chosen based on cargo size and legal road limits.

3. Heavy-Duty Frame
Made of high-tensile steel or aluminum (for lighter tare weight).

Reinforced beams to handle high payload capacity (25–60 tons).

4. Durable Flooring
Checker steel plate or hardwood planks.

Provides anti-slip surface and impact resistance.

5. Side and Rear Stake Pockets
Optional stakes or side panels can be inserted.

Help contain cargo or support tarpaulins.

6. Lashing Rings & Rope Hooks
Built-in rings for chains, straps, and rope tie-downs.

Essential for securing cargo safely.

7. Braking System
Dual-line pneumatic brakes with ABS.

Reliable braking even under heavy load.

8. Suspension Options
Mechanical (leaf spring) or air suspension.

Air suspension improves ride quality and reduces cargo shock.

9. Axles & Tires
Typically 2 or 3 axles, equipped with dual tires.

Tire size: 11.00R20 or 12R22.5 commonly used.

10. Landing Gear
Manual two-speed landing legs for parking and stability.

11. Kingpin
2" or 3.5", compatible with standard tractor heads.

12. Lighting & Reflectors
Full set of LED tail lights, turn signals, and reflectors for road safety.
